AMD · 2020
AMD WRX80
The AMD WRX80 is a chipset for workstation platforms, released in 2020. It supports the sWRX8 socket and provides PCIe 4.0 connectivity.
The AMD WRX80 is a chipset designed for AMD's workstation platforms, specifically for the sWRX8 socket. It was released in 2020 and is fabricated on a 14 nm process with a TDP of 15 W. The chipset provides 8 PCIe 4.0 lanes, 4 SATA III ports, 8 USB 3.2 Gen 2 ports, and 4 USB 2.0 ports. It supports ECC memory and CPU overclocking. The WRX80 is hardware-wise identical to the EPYC/Threadripper IO die, indicating its integration with AMD's high-end desktop and server processors.
Specifications
| Socket | sWRX8 |
|---|---|
| Platform | sWRX8 |
| Process node unverified | 14 nm |
| TDP unverified | 15 W |
| PCIe version unverified | 4.0 |
| Total PCIe lanes (chipset) unverified | 8 |
| ECC memory support unverified | Yes |
| SATA III ports unverified | 4 |
| USB 3.2 Gen 2 ports unverified | 8 |
| USB 2.0 ports unverified | 4 |
| CPU overclocking unverified | Yes |
| Release year unverified | 2020 |
| Notes unverified | HW-wise identical to EPYC/Threadripper IO die |
