AMD · 2007
AMD Radeon HD 3870
The AMD Radeon HD 3870 is a graphics card released in 2007, based on the TeraScale architecture with the RV670 XT chip.
The AMD Radeon HD 3870 is a graphics card from 2007, built on the TeraScale architecture using the RV670 XT GPU on a 55 nm process. It features 320 shading units, a base clock of 777 MHz, and 0.5 GB of GDDR3 memory on a 256-bit bus, delivering a memory bandwidth of 57.6 GB/s. The card has a TDP of 106 W and uses a PCIe 2.0 x16 interface. It supports DirectX 10.1 and OpenGL 3.3. The launch MSRP was 219 USD.
Specifications
| Architecture unverified | TeraScale |
|---|---|
| GPU chip unverified | RV670 XT |
| Process node unverified | 55 nm |
| Shading units unverified | 320 |
| Base clock unverified | 777 MHz |
| Memory size unverified | 0.5 GB |
| Memory type unverified | GDDR3 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 57.6 GB/s |
| Board power (TDP) unverified | 106 W |
| Bus interface unverified | PCIe 2.0 x16 |
| DirectX support unverified | 10.1 |
| OpenGL support unverified | 3.3 |
| Release date unverified | 2007-11-19 |
| Release year unverified | 2007 |
| Launch MSRP unverified | 219 USD |
