NVIDIA · 2019
NVIDIA GeForce RTX2060 SUPER
The NVIDIA GeForce RTX 2060 SUPER is a mid-range graphics card released in 2019, based on the Turing architecture with 8 GB GDDR6 memory.
The NVIDIA GeForce RTX 2060 SUPER is a graphics card released on July 9, 2019, with a launch MSRP of $399. It is built on the Turing architecture using the TU106-410 GPU chip on a 12 nm process. The card features 2176 shading units, 34 ray tracing cores, and 272 tensor cores, with base and boost clocks of 1470 MHz and 1650 MHz respectively. It has 8 GB of GDDR6 memory on a 256-bit bus, providing a memory bandwidth of 448 GB/s. The board power (TDP) is 175 W, requiring one 8-pin power connector. It supports PCIe 3.0 x16 interface and offers display outputs including 1x HDMI 2.0b, 3x DisplayPort 1.4a, and 1x USB-C. The card supports DirectX 12 Ultimate, Vulkan 1.3, and OpenGL 4.6.
Specifications
| Architecture unverified | Turing |
|---|---|
| GPU chip unverified | TU106-410 |
| Process node unverified | 12 nm |
| Shading units unverified | 2176 |
| Ray tracing cores unverified | 34 |
| Tensor / AI cores unverified | 272 |
| Base clock unverified | 1470 MHz |
| Boost clock unverified | 1650 MHz |
| Memory size unverified | 8 GB |
| Memory type unverified | GDDR6 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 448 GB/s |
| Board power (TDP) unverified | 175 W |
| Power connectors unverified | 1x 8-pin |
| Bus interface unverified | PCIe 3.0 x16 |
| Display outputs unverified | 1x HDMI 2.0b, 3x DisplayPort 1.4a, 1x USB-C |
| DirectX support unverified | 12 Ultimate |
| Vulkan support unverified | 1.3 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2019-07-09 |
| Release year unverified | 2019 |
| Launch MSRP unverified | 399 USD |
