NVIDIA · 2019
NVIDIA GeForce RTX2060
The NVIDIA GeForce RTX 2060 is a mid-range graphics card released in 2019, based on the Turing architecture.
The NVIDIA GeForce RTX 2060 is a mid-range graphics card released on January 15, 2019, with a launch MSRP of $349. It is based on the Turing architecture and uses the TU106-200A GPU chip fabricated on a 12 nm process. The card features 1920 shading units, 30 ray tracing cores, and 240 Tensor/AI cores. Its base clock is 1365 MHz, with a boost clock of 1680 MHz. It has 6 GB of GDDR6 memory on a 192-bit bus, providing a memory bandwidth of 336 GB/s. The board power (TDP) is 160 W, requiring one 8-pin power connector. It supports PCIe 3.0 x16 and offers display outputs including HDMI 2.0b, DisplayPort 1.4a, and DVI-D. The card supports DirectX 12 Ultimate, Vulkan 1.3, and OpenGL 4.6. It is the successor to the GeForce GTX 1060 and was succeeded by the GeForce RTX 3060.
Specifications
| Architecture unverified | Turing |
|---|---|
| GPU chip unverified | TU106-200A |
| Process node unverified | 12 nm |
| Shading units unverified | 1920 |
| Ray tracing cores unverified | 30 |
| Tensor / AI cores unverified | 240 |
| Base clock unverified | 1365 MHz |
| Boost clock unverified | 1680 MHz |
| Memory size unverified | 6 GB |
| Memory type unverified | GDDR6 |
| Memory bus unverified | 192 bit |
| Memory bandwidth unverified | 336 GB/s |
| Board power (TDP) unverified | 160 W |
| Power connectors unverified | 1x 8-pin |
| Bus interface unverified | PCIe 3.0 x16 |
| Display outputs unverified | HDMI 2.0b, DisplayPort 1.4a, DVI-D |
| DirectX support unverified | 12 Ultimate |
| Vulkan support unverified | 1.3 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2019-01-15 |
| Release year unverified | 2019 |
| Launch MSRP unverified | 349 USD |
| Successor unverified | GeForce RTX 3060 |
| Predecessor unverified | GeForce GTX 1060 |
