NVIDIA GeForce RTX2070
The NVIDIA GeForce RTX 2070 is a graphics card released in 2018, based on the Turing architecture with TU106-400 chip.
The NVIDIA GeForce RTX 2070 is a graphics card from NVIDIA's Turing series, launched on October 17, 2018. It features the TU106-400 GPU built on a 12 nm process, with 2304 shading units, 36 ray tracing cores, and 288 Tensor cores. The card operates at a base clock of 1410 MHz and a boost clock of 1620 MHz, with 8 GB of GDDR6 memory on a 256-bit bus, providing 448 GB/s bandwidth. It has a TDP of 175 W and requires one 8-pin power connector. The RTX 2070 supports PCIe 3.0 x16 and offers display outputs including HDMI 2.0b, DisplayPort 1.4a, and USB-C. It supports DirectX 12 Ultimate, Vulkan 1.3, and OpenGL 4.6. The card succeeded the GeForce GTX 1070 and was succeeded by the GeForce RTX 3070. Its launch MSRP was 499 USD.
Specifications
| Architecture unverified | Turing |
|---|---|
| GPU chip unverified | TU106-400 |
| Process node unverified | 12 nm |
| Shading units unverified | 2304 |
| Ray tracing cores unverified | 36 |
| Tensor / AI cores unverified | 288 |
| Base clock unverified | 1410 MHz |
| Boost clock unverified | 1620 MHz |
| Memory size unverified | 8 GB |
| Memory type unverified | GDDR6 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 448 GB/s |
| Board power (TDP) unverified | 175 W |
| Power connectors unverified | 1x 8-pin |
| Bus interface unverified | PCIe 3.0 x16 |
| Display outputs unverified | HDMI 2.0b, DisplayPort 1.4a, USB-C |
| DirectX support unverified | 12 Ultimate |
| Vulkan support unverified | 1.3 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2018-10-17 |
| Release year unverified | 2018 |
| Launch MSRP unverified | 499 USD |
| Successor unverified | GeForce RTX 3070 |
| Predecessor unverified | GeForce GTX 1070 |
