NVIDIA · 2019
NVIDIA GeForce RTX2080 SUPER
The NVIDIA GeForce RTX 2080 SUPER is a high-end graphics card released in 2019, based on the Turing architecture.
The NVIDIA GeForce RTX 2080 SUPER is a high-end graphics card released on July 23, 2019, with a launch MSRP of $699. It is based on the Turing architecture and uses the TU104-450 GPU chip built on a 12 nm process. The card features 3072 shading units, 48 ray tracing cores, and 384 Tensor cores, with base and boost clocks of 1650 MHz and 1815 MHz respectively. It has 8 GB of GDDR6 memory on a 256-bit bus, providing a memory bandwidth of 496 GB/s. The board power (TDP) is 250 W, requiring one 6-pin and one 8-pin power connector. It connects via PCIe 3.0 x16 and offers display outputs including 1x HDMI 2.0b, 3x DisplayPort 1.4a, and 1x USB-C. The card supports DirectX 12 Ultimate (12_2), Vulkan 1.3, and OpenGL 4.6. It succeeded the GeForce RTX 2080 and was succeeded by the GeForce RTX 3080.
Specifications
| Architecture unverified | Turing |
|---|---|
| GPU chip unverified | TU104-450 |
| Process node unverified | 12 nm |
| Shading units unverified | 3072 |
| Ray tracing cores unverified | 48 |
| Tensor / AI cores unverified | 384 |
| Base clock unverified | 1650 MHz |
| Boost clock unverified | 1815 MHz |
| Memory size unverified | 8 GB |
| Memory type unverified | GDDR6 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 496 GB/s |
| Board power (TDP) unverified | 250 W |
| Power connectors unverified | 1x 6-pin + 1x 8-pin |
| Bus interface unverified | PCIe 3.0 x16 |
| Display outputs unverified | 1x HDMI 2.0b, 3x DisplayPort 1.4a, 1x USB-C |
| DirectX support unverified | 12 Ultimate (12_2) |
| Vulkan support unverified | 1.3 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2019-07-23 |
| Release year unverified | 2019 |
| Launch MSRP unverified | 699 USD |
| Successor unverified | GeForce RTX 3080 |
| Predecessor unverified | GeForce RTX 2080 |
