NVIDIA GeForce RTX3060 Ti
The NVIDIA GeForce RTX 3060 Ti is a mid-range graphics card released in December 2020, based on the Ampere architecture.
The NVIDIA GeForce RTX 3060 Ti is a mid-range graphics card released on December 2, 2020, with a launch MSRP of $399. It is built on the Ampere architecture using an 8 nm process node and features the GA104-200 GPU chip. The card includes 4864 shading units, 38 ray tracing cores, and 152 Tensor/AI cores, with base and boost clocks of 1410 MHz and 1665 MHz respectively. It is equipped with 8 GB of GDDR6 memory on a 256-bit bus, providing a memory bandwidth of 448 GB/s. The RTX 3060 Ti has a board power (TDP) of 200 W and requires one 12-pin power connector. It supports PCIe 4.0 x16 interface and offers display outputs including HDMI 2.1 and DisplayPort 1.4a. The card supports DirectX 12 Ultimate, Vulkan 1.3, and OpenGL 4.6.
Specifications
| Architecture unverified | Ampere |
|---|---|
| GPU chip unverified | GA104-200 |
| Process node unverified | 8 nm |
| Shading units unverified | 4864 |
| Ray tracing cores unverified | 38 |
| Tensor / AI cores unverified | 152 |
| Base clock unverified | 1410 MHz |
| Boost clock unverified | 1665 MHz |
| Memory size unverified | 8 GB |
| Memory type unverified | GDDR6 |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 448 GB/s |
| Board power (TDP) unverified | 200 W |
| Power connectors unverified | 1x 12-pin |
| Bus interface unverified | PCIe 4.0 x16 |
| Display outputs unverified | HDMI 2.1, DisplayPort 1.4a |
| DirectX support unverified | 12 Ultimate |
| Vulkan support unverified | 1.3 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2020-12-02 |
| Release year unverified | 2020 |
| Launch MSRP unverified | 399 USD |
