NVIDIA · 2021
NVIDIA GeForce RTX3060
The NVIDIA GeForce RTX3060 is a mid-range graphics card released in 2021, based on the Ampere architecture.
The NVIDIA GeForce RTX3060 is a mid-range graphics card released on February 25, 2021, with a launch MSRP of $329. It is built on the Ampere architecture using an 8 nm process node and features the GA106-300 GPU chip. The card includes 3584 shading units, 28 ray tracing cores, and 112 Tensor/AI cores, with base and boost clocks of 1320 MHz and 1777 MHz respectively. It comes with 12 GB of GDDR6 memory on a 192-bit bus, providing a memory bandwidth of 360 GB/s. The board power (TDP) is 170 W and requires a single 12-pin power connector. It supports PCIe 4.0 x16 interface and offers display outputs including HDMI 2.1 and DisplayPort 1.4a. The card supports DirectX 12 Ultimate, Vulkan 1.3, and OpenGL 4.6.
Specifications
| Architecture unverified | Ampere |
|---|---|
| GPU chip unverified | GA106-300 |
| Process node unverified | 8 nm |
| Shading units unverified | 3584 |
| Ray tracing cores unverified | 28 |
| Tensor / AI cores unverified | 112 |
| Base clock unverified | 1320 MHz |
| Boost clock unverified | 1777 MHz |
| Memory size unverified | 12 GB |
| Memory type unverified | GDDR6 |
| Memory bus unverified | 192 bit |
| Memory bandwidth unverified | 360 GB/s |
| Board power (TDP) unverified | 170 W |
| Power connectors unverified | 1x 12-pin |
| Bus interface unverified | PCIe 4.0 x16 |
| Display outputs unverified | HDMI 2.1, DisplayPort 1.4a |
| DirectX support unverified | 12 Ultimate |
| Vulkan support unverified | 1.3 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2021-02-25 |
| Release year unverified | 2021 |
| Launch MSRP unverified | 329 USD |
