NVIDIA · 2020
NVIDIA GeForce RTX3080
The NVIDIA GeForce RTX3080 is a high-end graphics card released in 2020, based on the Ampere architecture and GA102 chip.
The NVIDIA GeForce RTX3080 is a graphics card from NVIDIA's GeForce 30 series, launched on September 17, 2020. It is built on the Ampere architecture using an 8 nm process node and features the GA102 GPU chip. The card includes 8704 shading units, 68 ray tracing cores, and 272 tensor/AI cores. It operates at a base clock of 1440 MHz and a boost clock of 1710 MHz. Memory configuration consists of 10 GB of GDDR6X on a 320-bit bus, providing a memory bandwidth of 760 GB/s. The card has a board power (TDP) of 320 W and requires a single 12-pin power connector. It interfaces via PCIe 4.0 x16 and offers display outputs including HDMI 2.1 and DisplayPort 1.4a. It supports DirectX 12 Ultimate, Vulkan 1.3, and OpenGL 4.6. The launch MSRP was 699 USD.
Specifications
| Architecture unverified | Ampere |
|---|---|
| GPU chip unverified | GA102 |
| Process node unverified | 8 nm |
| Shading units unverified | 8704 |
| Ray tracing cores unverified | 68 |
| Tensor / AI cores unverified | 272 |
| Base clock unverified | 1440 MHz |
| Boost clock unverified | 1710 MHz |
| Memory size unverified | 10 GB |
| Memory type unverified | GDDR6X |
| Memory bus unverified | 320 bit |
| Memory bandwidth unverified | 760 GB/s |
| Board power (TDP) unverified | 320 W |
| Power connectors unverified | 1x 12-pin |
| Bus interface unverified | PCIe 4.0 x16 |
| Display outputs unverified | HDMI 2.1, DisplayPort 1.4a |
| DirectX support unverified | 12 Ultimate |
| Vulkan support unverified | 1.3 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2020-09-17 |
| Release year unverified | 2020 |
| Launch MSRP unverified | 699 USD |
