NVIDIA · 2022
NVIDIA GeForce RTX3090 Ti
The NVIDIA GeForce RTX 3090 Ti is a flagship graphics card released in March 2022, based on the Ampere architecture and featuring 24 GB of GDDR6X memory.
The NVIDIA GeForce RTX 3090 Ti is a high-end graphics card launched on March 29, 2022, as part of the Ampere architecture. It utilizes the GA102-350 GPU chip manufactured on an 8 nm process. The card features 10752 shading units, 84 ray tracing cores, and 336 tensor/AI cores, with base and boost clocks of 1560 MHz and 1860 MHz respectively. It is equipped with 24 GB of GDDR6X memory on a 384-bit bus, providing a memory bandwidth of 1008 GB/s. The board power (TDP) is 450 W, requiring a single 12-pin power connector. It connects via PCIe 4.0 x16 and offers display outputs including HDMI 2.1 and DisplayPort 1.4a. The card supports DirectX 12 Ultimate, Vulkan 1.3, and OpenGL 4.6. The launch MSRP was 1999 USD.
Specifications
| Architecture unverified | Ampere |
|---|---|
| GPU chip unverified | GA102-350 |
| Process node unverified | 8 nm |
| Shading units unverified | 10752 |
| Ray tracing cores unverified | 84 |
| Tensor / AI cores unverified | 336 |
| Base clock unverified | 1560 MHz |
| Boost clock unverified | 1860 MHz |
| Memory size unverified | 24 GB |
| Memory type unverified | GDDR6X |
| Memory bus unverified | 384 bit |
| Memory bandwidth unverified | 1008 GB/s |
| Board power (TDP) unverified | 450 W |
| Power connectors unverified | 1x 12-pin |
| Bus interface unverified | PCIe 4.0 x16 |
| Display outputs unverified | HDMI 2.1, DisplayPort 1.4a |
| DirectX support unverified | 12 Ultimate |
| Vulkan support unverified | 1.3 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2022-03-29 |
| Release year unverified | 2022 |
| Launch MSRP unverified | 1999 USD |
