NVIDIA · 2023
NVIDIA GeForce RTX4060 Ti
The NVIDIA GeForce RTX 4060 Ti is a graphics card released in 2023, based on the Ada Lovelace architecture with 8 GB GDDR6 memory.
The NVIDIA GeForce RTX 4060 Ti is a mid-range graphics card released on May 24, 2023, with a launch MSRP of 399 USD. It is built on the Ada Lovelace architecture using a 5 nm process node and features the AD106-350-A1 GPU chip. The card includes 4352 shading units, 34 ray tracing cores, and 136 Tensor/AI cores, with a base clock of 2310 MHz and a boost clock of 2535 MHz. It has 8 GB of GDDR6 memory on a 128-bit bus, providing a memory bandwidth of 288.0 GB/s. The card has a TDP of 160 W and requires a single 12-pin power connector. It connects via PCIe 4.0 x8 and offers display outputs including 1x HDMI 2.1 and 3x DisplayPort 1.4a. It supports DirectX 12 Ultimate, Vulkan 1.3, and OpenGL 4.6.
Specifications
| Architecture unverified | Ada Lovelace |
|---|---|
| GPU chip unverified | AD106-350-A1 |
| Process node unverified | 5 nm |
| Shading units unverified | 4352 |
| Ray tracing cores unverified | 34 |
| Tensor / AI cores unverified | 136 |
| Base clock unverified | 2310 MHz |
| Boost clock unverified | 2535 MHz |
| Memory size unverified | 8 GB |
| Memory type unverified | GDDR6 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 288.0 GB/s |
| Board power (TDP) unverified | 160 W |
| Power connectors unverified | 1x 12-pin |
| Bus interface unverified | PCIe 4.0 x8 |
| Display outputs unverified | 1x HDMI 2.1, 3x DisplayPort 1.4a |
| DirectX support unverified | 12 Ultimate |
| Vulkan support unverified | 1.3 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2023-05-24 |
| Release year unverified | 2023 |
| Launch MSRP unverified | 399 USD |
