NVIDIA · 2023
NVIDIA GeForce RTX4060
The NVIDIA GeForce RTX4060 is a mid-range graphics card released in 2023, based on the Ada Lovelace architecture and 5 nm process.
The NVIDIA GeForce RTX4060 is a mid-range graphics card released on June 29, 2023, with a launch MSRP of $299 USD. It is built on the Ada Lovelace architecture using the AD107-400-A1 GPU chip on a 5 nm process. The card features 3072 shading units, 24 ray tracing cores, and 96 Tensor/AI cores, with base and boost clocks of 1830 MHz and 2460 MHz respectively. It comes with 8 GB of GDDR6 memory on a 128-bit bus, providing a memory bandwidth of 272.0 GB/s. The board power (TDP) is 115 W, and it requires a single 12-pin power connector. The card uses a PCIe 4.0 x8 bus interface and offers display outputs including one HDMI 2.1 and three DisplayPort 1.4a. It supports DirectX 12 Ultimate, Vulkan 1.3, and OpenGL 4.6.
Specifications
| Architecture unverified | Ada Lovelace |
|---|---|
| GPU chip unverified | AD107-400-A1 |
| Process node unverified | 5 nm |
| Shading units unverified | 3072 |
| Ray tracing cores unverified | 24 |
| Tensor / AI cores unverified | 96 |
| Base clock unverified | 1830 MHz |
| Boost clock unverified | 2460 MHz |
| Memory size unverified | 8 GB |
| Memory type unverified | GDDR6 |
| Memory bus unverified | 128 bit |
| Memory bandwidth unverified | 272.0 GB/s |
| Board power (TDP) unverified | 115 W |
| Power connectors unverified | 1x 12-pin |
| Bus interface unverified | PCIe 4.0 x8 |
| Display outputs unverified | 1x HDMI 2.1, 3x DisplayPort 1.4a |
| DirectX support unverified | 12 Ultimate |
| Vulkan support unverified | 1.3 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2023-06-29 |
| Release year unverified | 2023 |
| Launch MSRP unverified | 299 USD |
