NVIDIA GeForce RTX4070 Super
The NVIDIA GeForce RTX 4070 Super is a graphics card released in 2024, based on the Ada Lovelace architecture and 5 nm process.
The NVIDIA GeForce RTX 4070 Super is a graphics card released on January 17, 2024, with a launch MSRP of 599 USD. It is built on the Ada Lovelace architecture using the AD104-350-A1 GPU chip fabricated on a 5 nm process node. The card features 7168 shading units, 56 ray tracing cores, and 224 Tensor/AI cores. It operates at a base clock of 1980 MHz and a boost clock of 2475 MHz. The memory subsystem includes 12 GB of GDDR6X memory on a 192-bit bus, providing a memory bandwidth of 504.2 GB/s. The board power (TDP) is 220 W, requiring a single 16-pin power connector. It connects via PCIe 4.0 x16 and offers display outputs of one HDMI 2.1 and three DisplayPort 1.4a. The card supports DirectX 12 Ultimate, Vulkan 1.3, and OpenGL 4.6.
Specifications
| Architecture unverified | Ada Lovelace |
|---|---|
| GPU chip unverified | AD104-350-A1 |
| Process node unverified | 5 nm |
| Shading units unverified | 7168 |
| Ray tracing cores unverified | 56 |
| Tensor / AI cores unverified | 224 |
| Base clock unverified | 1980 MHz |
| Boost clock unverified | 2475 MHz |
| Memory size unverified | 12 GB |
| Memory type unverified | GDDR6X |
| Memory bus unverified | 192 bit |
| Memory bandwidth unverified | 504.2 GB/s |
| Board power (TDP) unverified | 220 W |
| Power connectors unverified | 1x 16-pin |
| Bus interface unverified | PCIe 4.0 x16 |
| Display outputs unverified | 1x HDMI 2.1, 3x DisplayPort 1.4a |
| DirectX support unverified | 12 Ultimate |
| Vulkan support unverified | 1.3 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2024-01-17 |
| Release year unverified | 2024 |
| Launch MSRP unverified | 599 USD |
