NVIDIA · 2023
NVIDIA GeForce RTX4070 Ti
The NVIDIA GeForce RTX 4070 Ti is a graphics card released in 2023, based on the Ada Lovelace architecture and 5 nm process.
The NVIDIA GeForce RTX 4070 Ti is a graphics card released on January 5, 2023, with a launch MSRP of 799 USD. It is built on the Ada Lovelace architecture and uses the AD104-400-A1 GPU chip fabricated on a 5 nm process node. The card features 7680 shading units, 60 ray tracing cores, and 240 Tensor/AI cores, with a base clock of 2310 MHz and a boost clock of 2610 MHz. It has 12 GB of GDDR6X memory on a 192-bit bus, providing a memory bandwidth of 504.2 GB/s. The board power (TDP) is 285 W, requiring a single 16-pin power connector. It connects via PCIe 4.0 x16 and offers display outputs including one HDMI 2.1 and three DisplayPort 1.4a. The card supports DirectX 12 Ultimate (12_2), Vulkan 1.3, and OpenGL 4.6.
Specifications
| Architecture unverified | Ada Lovelace |
|---|---|
| GPU chip unverified | AD104-400-A1 |
| Process node unverified | 5 nm |
| Shading units unverified | 7680 |
| Ray tracing cores unverified | 60 |
| Tensor / AI cores unverified | 240 |
| Base clock unverified | 2310 MHz |
| Boost clock unverified | 2610 MHz |
| Memory size unverified | 12 GB |
| Memory type unverified | GDDR6X |
| Memory bus unverified | 192 bit |
| Memory bandwidth unverified | 504.2 GB/s |
| Board power (TDP) unverified | 285 W |
| Power connectors unverified | 1x 16-pin |
| Bus interface unverified | PCIe 4.0 x16 |
| Display outputs unverified | 1x HDMI 2.1, 3x DisplayPort 1.4a |
| DirectX support unverified | 12 Ultimate (12_2) |
| Vulkan support unverified | 1.3 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2023-01-05 |
| Release year unverified | 2023 |
| Launch MSRP unverified | 799 USD |
