NVIDIA · 2023
NVIDIA GeForce RTX4070
The NVIDIA GeForce RTX 4070 is a graphics card released in 2023, based on the Ada Lovelace architecture and manufactured on a 5 nm process.
The NVIDIA GeForce RTX 4070 is a graphics card from NVIDIA's GeForce 40 series, launched on April 13, 2023. It is built on the Ada Lovelace architecture and uses the AD104-250-A1 GPU chip fabricated on a 5 nm process. The card features 5888 shading units, 46 ray tracing cores, and 184 Tensor/AI cores. Its base clock is 1920 MHz with a boost clock of 2475 MHz. Memory configuration includes 12 GB of GDDR6X on a 192-bit bus, providing a memory bandwidth of 504.2 GB/s. The card has a total board power (TDP) of 200 W and requires a single 16-pin power connector. It connects via a PCIe 4.0 x16 interface and offers display outputs: one HDMI 2.1 and three DisplayPort 1.4a. Software support includes DirectX 12 Ultimate (12_2), Vulkan 1.3, and OpenGL 4.6. The launch MSRP was 599 USD.
Specifications
| Architecture unverified | Ada Lovelace |
|---|---|
| GPU chip unverified | AD104-250-A1 |
| Process node unverified | 5 nm |
| Shading units unverified | 5888 |
| Ray tracing cores unverified | 46 |
| Tensor / AI cores unverified | 184 |
| Base clock unverified | 1920 MHz |
| Boost clock unverified | 2475 MHz |
| Memory size unverified | 12 GB |
| Memory type unverified | GDDR6X |
| Memory bus unverified | 192 bit |
| Memory bandwidth unverified | 504.2 GB/s |
| Board power (TDP) unverified | 200 W |
| Power connectors unverified | 1x 16-pin |
| Bus interface unverified | PCIe 4.0 x16 |
| Display outputs unverified | 1x HDMI 2.1, 3x DisplayPort 1.4a |
| DirectX support unverified | 12 Ultimate (12_2) |
| Vulkan support unverified | 1.3 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2023-04-13 |
| Release year unverified | 2023 |
| Launch MSRP unverified | 599 USD |
