NVIDIA · 2024
NVIDIA GeForce RTX4080 Super
The NVIDIA GeForce RTX4080 Super is a high-end graphics card released in 2024, based on the Ada Lovelace architecture.
The NVIDIA GeForce RTX4080 Super is a graphics card released on January 31, 2024, with a launch MSRP of $999. It is built on the Ada Lovelace architecture and uses the AD103-400-A1 GPU chip fabricated on a 5 nm process. The card features 10240 shading units, 80 ray tracing cores, and 320 Tensor/AI cores. Its base clock is 2295 MHz, with a boost clock of 2550 MHz. It comes with 16 GB of GDDR6X memory on a 256-bit bus, providing a memory bandwidth of 736.3 GB/s. The board power (TDP) is 320 W, requiring a single 16-pin power connector. The card uses a PCIe 4.0 x16 bus interface and offers display outputs including one HDMI 2.1 and three DisplayPort 1.4a. It supports DirectX 12 Ultimate (12_2), Vulkan 1.3, and OpenGL 4.6.
Specifications
| Architecture unverified | Ada Lovelace |
|---|---|
| GPU chip unverified | AD103-400-A1 |
| Process node unverified | 5 nm |
| Shading units unverified | 10240 |
| Ray tracing cores unverified | 80 |
| Tensor / AI cores unverified | 320 |
| Base clock unverified | 2295 MHz |
| Boost clock unverified | 2550 MHz |
| Memory size unverified | 16 GB |
| Memory type unverified | GDDR6X |
| Memory bus unverified | 256 bit |
| Memory bandwidth unverified | 736.3 GB/s |
| Board power (TDP) unverified | 320 W |
| Power connectors unverified | 1x 16-pin |
| Bus interface unverified | PCIe 4.0 x16 |
| Display outputs unverified | 1x HDMI 2.1, 3x DisplayPort 1.4a |
| DirectX support unverified | 12 Ultimate (12_2) |
| Vulkan support unverified | 1.3 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2024-01-31 |
| Release year unverified | 2024 |
| Launch MSRP unverified | 999 USD |
