NVIDIA · 2022
NVIDIA GeForce RTX4090
The NVIDIA GeForce RTX 4090 is a high-end graphics card released in 2022, based on the Ada Lovelace architecture and 5 nm process.
The NVIDIA GeForce RTX 4090 is a flagship graphics card launched on October 12, 2022, with a launch MSRP of 1599 USD. It is built on the Ada Lovelace architecture and uses the AD102-300-A1 GPU chip fabricated on a 5 nm process. The card features 16384 shading units, 128 ray tracing cores, and 512 Tensor/AI cores, with base and boost clocks of 2235 MHz and 2520 MHz respectively. It is equipped with 24 GB of GDDR6X memory on a 384-bit bus, delivering a memory bandwidth of 1008.0 GB/s. The board power (TDP) is 450 W, requiring a single 16-pin power connector. It connects via PCIe 4.0 x16 and provides one HDMI 2.1 and three DisplayPort 1.4a outputs. The card supports DirectX 12 Ultimate, Vulkan 1.3, and OpenGL 4.6.
Specifications
| Architecture unverified | Ada Lovelace |
|---|---|
| GPU chip unverified | AD102-300-A1 |
| Process node unverified | 5 nm |
| Shading units unverified | 16384 |
| Ray tracing cores unverified | 128 |
| Tensor / AI cores unverified | 512 |
| Base clock unverified | 2235 MHz |
| Boost clock unverified | 2520 MHz |
| Memory size unverified | 24 GB |
| Memory type unverified | GDDR6X |
| Memory bus unverified | 384 bit |
| Memory bandwidth unverified | 1008.0 GB/s |
| Board power (TDP) unverified | 450 W |
| Power connectors unverified | 1x 16-pin |
| Bus interface unverified | PCIe 4.0 x16 |
| Display outputs unverified | 1x HDMI 2.1, 3x DisplayPort 1.4a |
| DirectX support unverified | 12 Ultimate |
| Vulkan support unverified | 1.3 |
| OpenGL support unverified | 4.6 |
| Release date unverified | 2022-10-12 |
| Release year unverified | 2022 |
| Launch MSRP unverified | 1599 USD |
