Fractal Design
Core 1100
The Fractal Design Core 1100 is a Micro ATX case supporting Mini ITX and Micro ATX motherboards, with dimensions 175 x 358 x 410 mm and a weight of 3.8 kg.
The Fractal Design Core 1100 is a compact Micro ATX case designed for small form factor builds. It supports Mini ITX and Micro ATX motherboards and has dimensions of 175 x 358 x 410 mm, weighing 3.8 kg. The case features four expansion slots and can accommodate a maximum GPU length of 350 mm and a CPU cooler height of up to 148 mm. Storage options include two 3.5" HDD or three 2.5" HDD/SSD, or a combination of one 3.5" HDD and one 2.5" drive, plus two 5.25" optical drive bays. Front I/O includes one USB 3.0, one USB 2.0, audio jacks, and power and HDD activity LEDs. It comes with one pre-installed 120 mm Fractal Design Silent Series fan and features a brushed aluminum-look side panel.
Specifications
| Supported motherboard form factors | Mini ITX, Micro ATX |
|---|---|
| Case size | Micro ATX |
| Dimensions (HxWxD) | 175 x 358 x 410 mm |
| Weight | 3.8 kg |
| Drive bays | 2x 3.5" HDD or 3x 2.5" HDD/SSD or 1x 2.5" HDD/SSD or 1x 3.5" HDD, 2x 5.25" ODD |
| Expansion slots | 4 |
| Max GPU length | 350 mm |
| Max CPU cooler height | 148 mm |
| Front I/O | 1x USB 3.0, 1x USB 2.0, Audio in/out, Power button with LED (white), HDD activity LED (white) |
| Pre-installed fans | 1x 120 mm Fractal Design Silent Series fan |
| Side panel material | Brushed aluminum-look |
