Fractal Design · 2016
Define Nano S Window
The Define Nano S Window is a Mini-ITX case from Fractal Design, released in 2016, featuring a clear side window and sound-dampened steel panel.
The Define Nano S Window is a compact Mini-ITX case from Fractal Design, released in 2016. It supports ITX motherboards and measures 203 x 330 x 400 mm, weighing 5.0 kg. The case has two expansion slots and can accommodate GPUs up to 315 mm and CPU coolers up to 160 mm. It includes two pre-installed fans: a 140mm Dynamic GP-14 in the front and a 120mm Dynamic GP-12 in the rear. Drive bays consist of two 3.5" HDD/2.5" SSD mounts and two dedicated 2.5" SSD mounts. Front I/O offers two USB 3.0 ports, audio jacks, a blue LED power button, HDD activity LED, and reset button. The left side panel features a clear transparent window, while the right side uses industrial sound-dampened steel. The case launched at an MSRP of 69 USD.
Specifications
| Supported motherboard form factors | ITX |
|---|---|
| Case size | Mini-ITX |
| Dimensions (HxWxD) | 203 x 330 x 400 mm |
| Weight | 5.0 kg |
| Drive bays | 2x 3.5" HDD/2.5" SSD, 2x 2.5" SSD |
| Expansion slots | 2 |
| Max GPU length | 315 mm |
| Max CPU cooler height | 160 mm |
| Front I/O | 2x USB 3.0, Audio in/out, Power button with LED (blue), HDD activity LED (blue), Reset button |
| Pre-installed fans | 1x 140mm Dynamic GP-14 (front), 1x 120mm Dynamic GP-12 (rear) |
| Side panel material | Clear transparent window (left), Industrial sound-dampened steel (right) |
| Release year | 2016 |
| Launch MSRP | 69 USD |
