Fractal Design
Define R5 Window
The Define R5 Window is a mid-tower case from Fractal Design with a clear side panel and sound-dampened steel on the right.
The Fractal Design Define R5 Window is a mid-tower case supporting ATX, Micro ATX, and Mini ITX motherboards. It measures 232 x 451 x 521 mm and weighs 10.3 kg. The case features 8x 3.5" HDD/2.5" SSD bays, 2x dedicated 2.5" SSD mounts, and 2x 5.25" drive bays. It has 7 expansion slots and can accommodate GPUs up to 310 mm and CPU coolers up to 180 mm. Front I/O includes 2x USB 3.0, 2x USB 2.0, audio jacks, and power/reset buttons with blue LEDs. Two pre-installed Fractal Design Dynamic GP-14 140 mm fans provide cooling. The left side panel has a clear window, while the right side uses industrial sound-dampened steel.
Specifications
| Supported motherboard form factors | ATX, Micro ATX, Mini ITX |
|---|---|
| Dimensions (HxWxD) | 232 x 451 x 521 mm |
| Weight | 10.3 kg |
| Drive bays | 8x 3.5" HDD/2.5" SSD, 2x 2.5" dedicated SSD, 2x 5.25" |
| Expansion slots | 7 |
| Max GPU length | 310 mm |
| Max CPU cooler height | 180 mm |
| Front I/O | 2x USB 3.0, 2x USB 2.0, Audio in/out, Power button with LED (blue), HDD activity LED (blue), Reset button |
| Pre-installed fans | 2x Fractal Design Dynamic GP-14 140 mm fans |
| Side panel material | Clear transparent window (left), Industrial sound-dampened steel (right) |
