Fractal Design
Define R5
The Define R5 is a mid-tower case from Fractal Design supporting ATX, Micro ATX, and Mini ITX motherboards.
The Define R5 is a mid-tower case from Fractal Design that supports ATX, Micro ATX, and Mini ITX motherboards. It measures 232 x 451 x 521 mm and weighs 10.7 kg. The case features industrial sound-dampened steel side panels and includes two pre-installed Fractal Design Dynamic GP-14 140 mm fans (one front, one rear). Drive bays include eight 3.5" HDD/2.5" SSD positions, two dedicated 2.5" SSD slots, and two 5.25" bays. Expansion slots total seven. Maximum GPU length is 310 mm and maximum CPU cooler height is 180 mm. Front I/O offers two USB 3.0 ports, two USB 2.0 ports, audio in/out, a power button with blue LED, HDD activity LED (blue), and a reset button.
Specifications
| Supported motherboard form factors | ATX, Micro ATX, Mini ITX |
|---|---|
| Dimensions (HxWxD) | 232 x 451 x 521 |
| Weight | 10.7 kg |
| Drive bays | 8x 3.5" HDD/2.5" SSD, 2x 2.5" dedicated SSD, 2x 5.25" |
| Expansion slots | 7 |
| Max GPU length | 310 mm |
| Max CPU cooler height | 180 mm |
| Front I/O | 2x USB 3.0, 2x USB 2.0, Audio in/out, Power button with LED (blue), HDD activity LED (blue), Reset button |
| Pre-installed fans | 2x Fractal Design Dynamic GP-14 140 mm fans (1 front, 1 rear) |
| Side panel material | Industrial sound-dampened steel |
