Fractal Design
Define Xl R2
The Define XL R2 is a full tower case from Fractal Design, designed for high-end builds with support for XL-ATX motherboards and extensive storage options.
The Fractal Design Define XL R2 is a full tower case that supports ATX, Micro ATX, mini-ITX, E-ATX, and XL-ATX motherboards. It measures 232 x 559 x 560 mm and weighs 16.4 kg. The case features 8 internal 3.5" HDD/SSD bays and 4 external 5.25" bays, along with 9 expansion slots. Maximum GPU length is 330 mm, and maximum CPU cooler height is 170 mm. Front I/O includes 2x USB 3.0, 2x USB 2.0, audio jacks, a power button with blue LED, a reset button, and a fan controller behind the door. It comes pre-installed with three 140 mm Silent Series R2 fans (hydraulic bearing, 1000 RPM). The side panel is made of industrial sound-dampened steel.
Specifications
| Supported motherboard form factors | ATX, Micro ATX, mini-ITX, E-ATX, XL-ATX |
|---|---|
| Case size | Full Tower |
| Dimensions (HxWxD) | 232 x 559 x 560 mm |
| Weight | 16.4 kg |
| Drive bays | 8x 3.5" HDD/SSD, 4x 5.25" |
| Expansion slots | 9 |
| Max GPU length | 330 mm |
| Max CPU cooler height | 170 mm |
| Front I/O | 2x USB 3.0, 2x USB 2.0, Audio in/out, Power button with LED (blue), Reset button, Fan controller (behind door) |
| Pre-installed fans | 3x 140 mm Silent Series R2 fans (hydraulic bearing, 1000 RPM) |
| Side panel material | Industrial sound-dampened steel |
