Fractal Design
Epoch Xl
The Fractal Design Epoch Xl is a mid-tower case supporting E-ATX (up to 275 mm), ATX, mATX, and ITX motherboards.
The Fractal Design Epoch Xl is a mid-tower case with dimensions 503 x 240 x 509 mm and a weight of 9.36 kg. It supports E-ATX motherboards up to 275 mm wide, as well as ATX, mATX, and ITX form factors. The case features two 3.5/2.5-inch and two 2.5-inch drive bays, seven expansion slots, and can accommodate GPUs up to 425 mm long and CPU coolers up to 176 mm tall. Front I/O includes one USB Type-C 20 Gbps, two USB Type-A 5 Gbps, and an audio/mic combo jack. It comes pre-installed with three 140 mm Momentum 14 fans. Side panel options include steel (Solid version) or tempered glass (TG & RGB versions).
Specifications
| Supported motherboard form factors | E-ATX up to 275 mm, ATX, mATX, ITX |
|---|---|
| Case size | Mid-Tower |
| Dimensions (HxWxD) | 503 x 240 x 509 |
| Weight | 9.36 kg |
| Drive bays | 2 x 3.5/2.5, 2 x 2.5 |
| Expansion slots | 7 |
| Max GPU length | 425 mm |
| Max CPU cooler height | 176 mm |
| Front I/O | 1x USB Type-C 20 Gbps, 2x USB Type-A 5 Gbps, 1x Audio/Mic Combo Jack |
| Pre-installed fans | 3 x 140 mm Momentum 14 |
| Side panel material | Steel (Solid version), Tempered Glass (TG & RGB) |
