Fractal Design

Focus G Mini

The Focus G Mini is a Micro-ATX Mini Tower case from Fractal Design, supporting mATX and ITX motherboards.

The Focus G Mini is a Micro-ATX Mini Tower case designed for mATX and ITX motherboards. It measures 205 x 383 x 464 mm and weighs 4.1 kg. The case offers drive bays including two 3.5" or 2.5" bays, one dedicated 2.5" bay, and two 5.25" bays. It has four expansion slots and can accommodate GPUs up to 380 mm in length and CPU coolers up to 165 mm in height. The front I/O includes one USB 3.0 port, one USB 2.0 port, audio in/out, and power and reset buttons. It comes with two pre-installed Silent Series LL 120 mm White LED fans. The left side panel features a clear transparent window, while the right side is steel.

Specifications

Supported motherboard form factors mATX, ITX
Case size Micro-ATX Mini Tower
Dimensions (HxWxD) 205 x 383 x 464
Weight 4.1 kg
Drive bays 2x 3.5" or 2.5", 1x dedicated 2.5", 2x 5.25"
Expansion slots 4
Max GPU length 380 mm
Max CPU cooler height 165 mm
Front I/O 1x USB 3.0, 1x USB 2.0, Audio in/out, Power button, Reset button
Pre-installed fans 2x Silent Series LL 120 mm White LED fans
Side panel material Clear transparent window (left), Steel (right)
