Meshify 2 Compact Lite

The Meshify 2 Compact Lite is a mid-tower case from Fractal Design, supporting ATX, mATX, and Mini-ITX motherboards.

The Meshify 2 Compact Lite is a mid-tower case with dimensions 424 x 210 x 475 mm and a weight of 8.1 kg. It supports ATX, mATX, and Mini-ITX motherboards. The case has 7 expansion slots, drive bays for 2x 3.5"/2.5" universal and 2x dedicated 2.5" drives (4 positions total). Maximum GPU length is 345 mm, and maximum CPU cooler height is 169 mm. Front I/O includes 2x USB 3.0, audio I/O, power and reset buttons, and is USB type-C ready. The left side panel is tempered glass, the right is steel. It comes pre-installed with 2x Aspect 14 fans at the front and 1x Aspect 12 at the rear.

Specifications

Supported motherboard form factors ATX, mATX, Mini-ITX
Case size Mid Tower
Dimensions (HxWxD) 424 x 210 x 475
Weight 8.1 kg
Drive bays 2x 3.5"/2.5" universal, 2x dedicated 2.5" (4 positions total)
Expansion slots 7
Max GPU length 345 mm
Max CPU cooler height 169 mm
Front I/O 2x USB 3.0, Audio I/O, Power button, Reset button, USB type-C ready
Pre-installed fans 2x Aspect 14 (front), 1x Aspect 12 (rear) (standard version)
Side panel material Tempered glass (left), Steel (right)
