AMD · 2007
AMD 570X
The AMD 570X is a chipset for Socket AM2 motherboards, released in 2007 as part of the AMD 570X CrossFire Chipset platform.
The AMD 570X is a chipset released in 2007 for Socket AM2 processors. It is essentially the RD550 chipset renamed and supports AMD's CrossFire multi-GPU technology with two PCIe x16 slots that operate at x8 when CrossFire is enabled. The chipset provides 20 PCIe lanes (PCIe 1.0a), four SATA III ports, and ten USB 2.0 ports. It supports up to 8 GB of DDR2-800 memory in a dual-channel configuration. CPU overclocking is supported. The 570X was used in motherboards for the AMD platform.
Specifications
| Socket unverified | Socket AM2 |
|---|---|
| Platform unverified | AMD 570X CrossFire Chipset |
| PCIe version unverified | PCIe 1.0a |
| Total PCIe lanes (chipset) unverified | 20 |
| Memory support unverified | DDR2-800 |
| Max memory unverified | 8 GB |
| Memory channels unverified | 2 |
| SATA III ports unverified | 4 |
| USB 2.0 ports unverified | 10 |
| CPU overclocking unverified | Yes |
| Release year unverified | 2007 |
| Notes unverified | The 570X is essentially the RD550 chipset, renamed. It supports CrossFire with two PCIe x16 slots operating at x8 when CrossFire is enabled. |
