AMD 690G
The AMD 690G is a chipset for Socket AM2 motherboards, released in 2007. It features integrated graphics and supports DDR2 memory.
The AMD 690G is a chipset released on February 28, 2007, succeeding the Radeon Xpress 1600 and preceding the AMD 700 chipset series. It is designed for Socket AM2 and supports DDR2 memory with a maximum capacity of 8 GB across two channels, without ECC support. The chipset is manufactured on an 80 nm process with a TDP of 13.8 W. It provides 24 PCIe 1.0 lanes, 4 SATA III ports, 10 USB 2.0 ports, and integrated Gigabit Ethernet. Compatible form factors include Micro ATX, ATX, and Mini-ITX.
Specifications
| Socket unverified | Socket AM2 |
|---|---|
| Process node unverified | 80 nm |
| TDP unverified | 13.8 W |
| PCIe version unverified | 1.0 |
| Total PCIe lanes (chipset) unverified | 24 |
| Memory support unverified | DDR2 |
| Max memory unverified | 8 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports unverified | 4 |
| USB 2.0 ports unverified | 10 |
| Integrated Ethernet unverified | Gigabit Ethernet |
| Supported form factors unverified | Micro ATX, ATX, Mini-ITX |
| Release date unverified | 2007-02-28 |
| Release year unverified | 2007 |
| Successor unverified | AMD 700 chipset series |
| Predecessor unverified | Radeon Xpress 1600 |
