AMD 690V
The AMD 690V is a chipset for Socket AM2, released in 2007, offering integrated graphics with VGA output.
The AMD 690V is a chipset designed for Socket AM2 processors, released in 2007. It is built on an 80 nm process with a TDP of 13.8 W. The chipset supports DDR2 memory across two channels and does not support ECC memory. It provides 24 PCIe lanes (version 1.0) and integrates Gigabit Ethernet. The 690V is a simplified version of the 690G, lacking TMDS/HDMI support and limited to VGA output. It is compatible with Micro ATX and ATX form factors.
Specifications
| Socket unverified | Socket AM2 |
|---|---|
| Platform unverified | AMD |
| Process node unverified | 80 nm |
| TDP unverified | 13.8 W |
| PCIe version unverified | 1.0 |
| Total PCIe lanes (chipset) unverified | 24 |
| Memory support unverified | DDR2 |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| Integrated Ethernet unverified | Gigabit Ethernet |
| Supported form factors unverified | Micro ATX, ATX |
| Release year unverified | 2007 |
| Notes unverified | 690V is a simplified version of 690G without TMDS/HDMI support, limited to VGA output. |
