AMD · 2008
AMD 760G
The AMD 760G is a chipset for Socket AM3, part of the AMD 700 series, released in 2008.
The AMD 760G is a chipset in the AMD 700 chipset series, designed for Socket AM3. It is built on a 55 nm process node and features PCIe 2.0 with 20 total lanes from the chipset. It supports DDR3 memory at 533 MHz, without ECC support. The chipset includes 6 SATA III ports and 14 USB 2.0 ports. It integrates a Radeon 3000 Graphics GPU clocked at 350 MHz, sharing system memory (DDR3 533 MHz). Power consumption ranges from 5.1 to 6.1 W. The chipset is used with AMD processors for the AM3 socket.
Specifications
| Socket unverified | Socket AM3 |
|---|---|
| Platform unverified | AMD 700 chipset series |
| Process node unverified | 55 nm |
| PCIe version unverified | 2.0 |
| Total PCIe lanes (chipset) unverified | 20 |
| Memory support unverified | DDR3 533 MHz |
| ECC memory support unverified | No |
| SATA III ports unverified | 6 |
| USB 2.0 ports unverified | 14 |
| Release year unverified | 2008 |
| Notes unverified | Integrated graphics: Radeon 3000 Graphics GPU 350 MHz, memory shared DDR3 533 MHz, power consumption 5.1-6.1 W |
