AMD 785G chipset
The AMD 785G chipset, released in 2009, is a 55 nm chipset for AM3 socket supporting DDR3 memory and integrated graphics with DirectX 10.1.
The AMD 785G chipset is a 55 nm chipset released in 2009 for the AM3 socket. It has a TDP of 11 W and supports DDR3 memory with a maximum capacity of 16 GB across two channels. The chipset provides 6 SATA III ports and 14 USB 2.0 ports. It features PCIe 2.0 with 16 lanes, configurable as one PCIe 2.0 x16 or two PCIe 2.0 x8. The integrated graphics support DirectX 10.1, UVD2, Side-port memory, and outputs including HDMI/HDCP and DisplayPort/DPCP. ECC memory is not supported.
Specifications
| Socket unverified | AM3 |
|---|---|
| Platform unverified | AMD 785G |
| Process node unverified | 55 nm |
| TDP unverified | 11 W |
| PCIe version unverified | 2.0 |
| Total PCIe lanes (chipset) unverified | 16 |
| Memory support unverified | DDR3 |
| Max memory unverified | 16 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports unverified | 6 |
| USB 2.0 ports unverified | 14 |
| Release year unverified | 2009 |
| Notes unverified | DirectX 10.1, UVD2, Side-port memory, HDMI/HDCP, DisplayPort/DPCP, OR two PCIe 2.0 x16 |
