AMD M690 chipset
The AMD M690 chipset is a mobile chipset for Socket S1, released in February 2007 on an 80 nm process.
The AMD M690 chipset is a mobile chipset designed for Socket S1, released in February 2007. It is built on an 80 nm process with a TDP of 4.0 W. The chipset supports DDR2 memory and provides 4 SATA III ports and 10 USB 2.0 ports. It features DirectX 9.0, AVIVO technology, and DVI/HDCP support, but lacks HDMI. It also includes Powerplay 7.0 power management. The M690 is intended for use with AMD mobile processors in Socket S1.
Specifications
| Socket unverified | Socket S1 |
|---|---|
| Platform unverified | Mobile |
| Process node unverified | 80 nm |
| TDP unverified | 4.0 W |
| Memory support unverified | DDR2 |
| ECC memory support unverified | No |
| SATA III ports unverified | 4 |
| USB 2.0 ports unverified | 10 |
| Release date unverified | 2007-02 |
| Release year unverified | 2007 |
| Notes unverified | DirectX 9.0, AVIVO, DVI/HDCP, no HDMI, Powerplay 7.0 |
