AMD · 2007
AMD M690T
The AMD M690T is a mobile chipset released in 2007, supporting Socket S1 and DDR2 memory.
The AMD M690T is a mobile chipset released in 2007, built on an 80 nm process with a TDP of 13.8 W. It supports up to 128 GB of DDR2 memory and does not support ECC memory. The chipset provides 4 SATA III ports and 10 USB 2.0 ports, along with integrated Gigabit Ethernet. It features optional 128 MB side-port memory. The M690T is paired with the SB600 southbridge and is compatible with COM Express Type 2, Mini-ITX, and Micro ATX form factors.
Specifications
| Socket unverified | Socket S1 |
|---|---|
| Platform unverified | mobile |
| Process node unverified | 80 nm |
| TDP unverified | 13.8 W |
| Memory support unverified | DDR2 |
| Max memory unverified | 128 GB |
| ECC memory support unverified | No |
| SATA III ports unverified | 4 |
| USB 2.0 ports unverified | 10 |
| Integrated Ethernet unverified | Gigabit Ethernet |
| Supported form factors unverified | COM Express Type 2, Mini-ITX, Micro ATX |
| Release year unverified | 2007 |
| Notes unverified | M690T is a mobile chipset with optional 128 MB side-port memory; paired with SB600 southbridge. |
