Intel · 2012
Intel 82434NX 2x 82433NX
The Intel 82434NX 2x 82433NX is a chipset for Socket R workstation boards, released in 2012.
The Intel 82434NX 2x 82433NX is a chipset designed for Intel's Socket R platform, specifically used with the Intel Workstation Board W2600CR2. It supports DDR3 ECC memory types including UDIMM at 1333/1866 MHz, RDIMM at 1600 MHz, and LRDIMM at 1333 MHz, with a maximum capacity of 512 GB across four memory channels. The chipset provides 10 SATA III ports, 8 USB 2.0 ports, and integrated dual 1GbE Ethernet. It also supports Intel Rapid Storage Technology. The board form factor is custom 14.2" x 15". The chipset was released in January 2012 and discontinued on January 31, 2014.
Specifications
| Socket | Socket R |
|---|---|
| Platform | Intel Workstation Board W2600CR2 |
| Memory support | DDR3 ECC UDIMM 1333/1866, RDIMM 1600, LRDIMM 1333 |
| Max memory | 512 GB |
| Memory channels | 4 |
| ECC memory support | Yes |
| SATA III ports | 10 |
| USB 2.0 ports | 8 |
| Integrated Ethernet | 2x 1GbE |
| Intel Rapid Storage Technology | Yes |
| Supported form factors | Custom 14.2" x 15" |
| Release date | 2012-01 |
| Release year | 2012 |
| Discontinued | 2014-01-31 |
