Intel · 2011
Intel 82815EM
The Intel 82815EM is a 32 nm embedded chipset for BGA1023 sockets, supporting DDR3 memory and PCIe 2.0.
The Intel 82815EM is a chipset designed for embedded platforms, released in 2011. It uses a 32 nm process node and has a TDP of 35 W. The chipset supports DDR3 memory at 1066/1333 MHz with two channels and a maximum capacity of 16.6 GB, including ECC support. It provides 16 PCIe 2.0 lanes. The 82815EM is intended for use with processors in the BGA1023 socket.
Specifications
| Socket | BGA1023 |
|---|---|
| Platform | Embedded |
| Process node | 32 nm |
| TDP | 35 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 16 |
| Memory support | DDR3 1066/1333 |
| Max memory | 16.6 GB |
| Memory channels | 2 |
| ECC memory support | Yes |
| Release date | 2011-01-01 |
| Release year | 2011 |
