Intel 82820 82820DP
The Intel 82820 82820DP is a chipset released in 2013, featuring a 22 nm process node and a TDP of 7.5 W.
The Intel 82820 82820DP is a chipset designed for use with Intel processors in the FCBGA1170 socket. It was released on October 1, 2013, and built on a 22 nm process node with a thermal design power of 7.5 W. The chipset supports DDR3L memory at 1066 MHz, with a maximum capacity of 8 GB across two channels, but does not support ECC memory. It provides four PCIe 2.0 lanes, two SATA III ports, five USB 3.2 Gen 1 ports, and five USB 2.0 ports. Intel Rapid Storage Technology is not supported.
Specifications
| Socket | FCBGA1170 |
|---|---|
| Process node | 22 nm |
| TDP | 7.5 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 4 |
| Memory support | DDR3L 1066 |
| Max memory | 8 GB |
| Memory channels | 2 |
| ECC memory support | No |
| SATA III ports | 2 |
| USB 3.2 Gen 1 ports | 5 |
| USB 2.0 ports | 5 |
| Intel Rapid Storage Technology | No |
| Release date | 2013-10-01 |
| Release year | 2013 |
