Intel · 2004
Intel 82852GM
The Intel 82852GM is a mobile chipset for Socket 478, released in 2004 as part of the 852GM chipset.
The Intel 82852GM is a mobile chipset released in Q2 2004 for Socket 478 platforms. It is fabricated on a 90 nm process with a TDP of 3.2 W. The chipset supports DDR 200/266 memory up to 1 GB and does not support ECC memory. It features PCIe version 1.0a. The 82852GM is part of the 852GM chipset, paired with the ICH4-M south bridge. It includes integrated graphics with a 32-bit 3D Core running at 133 MHz. The chipset has been discontinued.
Specifications
| Socket unverified | Socket 478 |
|---|---|
| Platform unverified | Mobile |
| Process node | 90 nm |
| TDP unverified | 3.2 W |
| PCIe version | v1.0a |
| Memory support unverified | DDR 200/266 |
| Max memory unverified | 1 GB |
| ECC memory support unverified | No |
| Release date unverified | 2004-Q2 |
| Release year unverified | 2004 |
| Discontinued | Discontinued |
| Notes unverified | Part of 852GM chipset; south bridge ICH4-M; integrated graphics 32-bit 3D Core @ 133 MHz |
