Intel · 2014
Intel 82940GML
The Intel 82940GML is a mobile chipset released in 2014, designed for low-power laptops and embedded systems.
The Intel 82940GML is a mobile chipset introduced in 2014, built on a 22 nm process with a TDP of 7.5 W. It supports DDR3L 1333 memory up to 8 GB across two channels, without ECC support. The chipset provides 4 PCIe 2.0 lanes, 2 SATA III ports, 5 USB 3.2 Gen 1 ports, and 5 USB 2.0 ports. It uses the FCBGA1170 socket and is intended for use with compatible Intel processors in mobile platforms.
Specifications
| Socket | FCBGA1170 |
|---|---|
| Platform | Mobile |
| Process node | 22 nm |
| TDP | 7.5 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 4 |
| Memory support | DDR3L 1333 |
| Max memory | 8 GB |
| Memory channels | 2 |
| ECC memory support | No |
| SATA III ports | 2 |
| USB 3.2 Gen 1 ports | 5 |
| USB 2.0 ports | 5 |
| Release date | 2014-07-01 |
| Release year | 2014 |
