Intel · 2008
Intel 82PM45
The Intel 82PM45 is a mobile chipset released in 2008 for Socket P, part of the Cantiga platform.
The Intel 82PM45 is a mobile chipset introduced in July 2008 as part of the Cantiga platform. It is designed for Socket P and manufactured on a 65 nm process with a TDP of 7 W. The chipset supports DDR2 memory at 667/800 MHz and DDR3 memory at 800/1066 MHz, with a maximum capacity of 8 GB across two channels. It does not support ECC memory. For expansion, it provides 16 PCIe 1.0 lanes and uses DMI 1.0 for chipset-to-CPU communication. Storage connectivity includes four SATA III ports, and it offers 12 USB 2.0 ports. The 82PM45 succeeds the Intel PM965 and was succeeded by the Intel PM55.
Specifications
| Socket unverified | Socket P |
|---|---|
| Platform unverified | Cantiga |
| Process node unverified | 65 nm |
| TDP unverified | 7 W |
| PCIe version unverified | 1.0 |
| Total PCIe lanes (chipset) unverified | 16 |
| DMI version unverified | 1.0 |
| Memory support unverified | DDR2 667/800, DDR3 800/1066 |
| Max memory unverified | 8 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports unverified | 4 |
| USB 2.0 ports unverified | 12 |
| Release date unverified | 2008-07 |
| Release year unverified | 2008 |
| Successor unverified | Intel PM55 |
| Predecessor unverified | Intel PM965 |
