Intel · 2007
Intel 82X38
The Intel 82X38 is a chipset for LGA775 Core 2 platforms, released in 2007.
The Intel 82X38 is a chipset designed for Intel Core 2 processors on the LGA775 socket. It was released in September 2007 and discontinued in September 2009. Manufactured on a 90 nm process, it supports DDR3 memory up to 1333 MHz and DDR2 up to 1066 MHz, with a maximum capacity of 8 GB and ECC support. The chipset provides 32 PCIe 2.0 lanes, four SATA III ports, four USB 2.0 ports, and dual Gigabit Ethernet. It includes Intel Rapid Storage Technology and is used in custom and rack form factors, notably the Intel Server Board X38ML, which features a 1333 MHz front-side bus, integrated IPMI 2.0, four DDR2 DIMM slots, four SATA ports, and a 6” x 13” form factor. It supports 45 nm single, dual, and quad-core processors.
Specifications
| Socket | LGA775 |
|---|---|
| Platform unverified | Core 2 chipsets |
| Process node unverified | 90 nm |
| PCIe version unverified | 2.0 |
| Total PCIe lanes (chipset) unverified | 32 |
| Memory support unverified | DDR3 800/1066/1333, DDR2 667/800/1066 |
| Max memory | 8 GB |
| ECC memory support | Yes |
| SATA III ports | 4 |
| USB 2.0 ports | 4 |
| Integrated Ethernet | Double, GbE |
| Intel Rapid Storage Technology | Yes |
| Supported form factors | Custom, Rack |
| Release date unverified | 2007-09 |
| Release year | 2007 |
| Discontinued | 2009-09 |
| Notes | Intel® Server Board X38ML (HORIZONTAL POWER CONNECTOR) 1333 FSB, integrated IPMI 2.0, 4 DDR2 DIMM slots, four SATA Ports, 6’ x 13” form factor. RoHS Compliant and Pb-free 2nd level interconnect. Supports 45nm single, dual, and quad core |
