Intel 925X
The Intel 925X is a desktop chipset released in 2004 for LGA775 processors, supporting Pentium 4 and Pentium 4 Extreme Edition.
The Intel 925X is a desktop chipset released in June 2004 for the LGA775 socket. It supports Pentium 4 and Pentium 4 Extreme Edition processors. The chipset has a TDP of 12.3 W and features PCIe version 1.0a. It supports up to 4 GB of DDR2 memory at 400/533 MHz with dual-channel and ECC support. Storage includes 4 SATA III ports, and connectivity includes 8 USB 2.0 ports. The 925X uses the ICH6 or ICH6R south bridge. It succeeded the 875P and was succeeded by the 955X.
Specifications
| Socket unverified | LGA775 |
|---|---|
| Platform | Desktop |
| TDP unverified | 12.3 W |
| PCIe version unverified | 1.0a |
| Memory support unverified | DDR2 400/533 |
| Max memory unverified | 4 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | Yes |
| SATA III ports unverified | 4 |
| USB 2.0 ports unverified | 8 |
| Release date unverified | 2004-06 |
| Release year unverified | 2004 |
| Successor unverified | 955X |
| Predecessor unverified | 875P |
| Notes unverified | Supports Pentium 4 and Pentium 4 Extreme Edition; South Bridge ICH6/ICH6R |
