Intel · 2004
Intel 925XE
The Intel 925XE is a desktop chipset for LGA775 processors, released in 2004 as a successor to the Intel 925X.
The Intel 925XE is a chipset for desktop platforms, supporting LGA775 processors. It was released in November 2004 and succeeded by the Intel 955X. Manufactured on a 90 nm process, it has a TDP of 13.3 W. The chipset features PCIe 1.0a with 16 lanes and DMI 1.0. It supports DDR2 memory at 400/533 MHz with dual-channel configuration, up to 4 GB, including ECC memory. It provides 4 SATA III ports and 8 USB 2.0 ports. Integrated Ethernet is Intel PRO/1000. It does not support Intel Rapid Storage Technology but allows CPU overclocking. Supported form factor is ATX.
Specifications
| Socket unverified | LGA775 |
|---|---|
| Platform | Desktop |
| Process node unverified | 90 nm |
| TDP unverified | 13.3 W |
| PCIe version unverified | 1.0a |
| Total PCIe lanes (chipset) unverified | 16 |
| DMI version unverified | 1.0 |
| Memory support unverified | DDR2 400/533 |
| Max memory unverified | 4 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | Yes |
| SATA III ports unverified | 4 |
| USB 2.0 ports unverified | 8 |
| Integrated Ethernet unverified | Intel PRO/1000 |
| Intel Rapid Storage Technology unverified | No |
| CPU overclocking unverified | Yes |
| Supported form factors unverified | ATX |
| Release date unverified | 2004-11 |
| Release year unverified | 2004 |
| Successor unverified | Intel 955X |
| Predecessor unverified | Intel 925X |
