Intel · 2005
Intel 945G
The Intel 945G is a chipset for LGA 775 processors, released in May 2005 as part of the Lakeport-G platform.
The Intel 945G is a chipset released in May 2005 for the LGA 775 socket, part of the Lakeport-G platform. It is manufactured on a 90 nm process with a TDP of 22.2 W. The chipset supports up to 4 GB of DDR2 memory at 400/533/667 MHz across two channels, without ECC support. It provides 16 PCIe 1.0a lanes, four SATA III ports, and eight USB 2.0 ports. Integrated Ethernet supports 10/100/1000 Mbps. It does not include Intel Rapid Storage Technology.
Specifications
| Socket unverified | LGA 775 |
|---|---|
| Platform unverified | Lakeport-G |
| Process node unverified | 90 nm |
| TDP unverified | 22.2 W |
| PCIe version unverified | 1.0a |
| Total PCIe lanes (chipset) unverified | 16 |
| Memory support unverified | DDR2 400/533/667 |
| Max memory unverified | 4 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports unverified | 4 |
| USB 2.0 ports unverified | 8 |
| Integrated Ethernet unverified | 10/100/1000 |
| Intel Rapid Storage Technology unverified | No |
| Release date unverified | 2005-05 |
| Release year unverified | 2005 |
