Intel · 2006
Intel 945GT
The Intel 945GT is a mobile chipset released in 2006 for Socket M processors, part of the Calistoga platform.
The Intel 945GT is a mobile chipset introduced in January 2006 as part of the Calistoga platform. It is built on a 90 nm process with a TDP of 7 W. The chipset supports Socket M processors and provides 16 PCIe lanes (version 1.0a). Memory support includes DDR2 at 400, 533, and 667 MHz, with a maximum capacity of 4 GB across two channels. It features 4 SATA III ports and 8 USB 2.0 ports. The 945GT succeeded the Intel 915 Express and was succeeded by the Intel 965 Express.
Specifications
| Socket unverified | Socket M |
|---|---|
| Platform unverified | Calistoga |
| Process node unverified | 90 nm |
| TDP unverified | 7 W |
| PCIe version unverified | 1.0a |
| Total PCIe lanes (chipset) unverified | 16 |
| Memory support unverified | DDR2 400/533/667 |
| Max memory | 4 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports unverified | 4 |
| USB 2.0 ports unverified | 8 |
| Release date unverified | 2006-01 |
| Release year unverified | 2006 |
| Successor unverified | Intel 965 Express |
| Predecessor unverified | Intel 915 Express |
