Intel 945PM
The Intel 945PM is a mobile chipset for Socket M, part of the Calistoga platform, released in 2006.
The Intel 945PM is a chipset designed for mobile platforms, using Socket M and part of the Calistoga platform. It was released in January 2006 and manufactured on a 90 nm process with a TDP of 7 W. The chipset supports DDR2 memory at speeds of 400, 533, and 667 MHz, with a maximum capacity of 4 GB across two channels. It does not support ECC memory. For expansion, the 945PM provides 16 PCIe 1.0 lanes and uses DMI 1.0 for interconnect. It includes 4 SATA III ports and 8 USB 2.0 ports. This chipset is a successor to the Intel 915PM and was succeeded by the Intel 965PM.
Specifications
| Socket unverified | Socket M |
|---|---|
| Platform unverified | Calistoga |
| Process node unverified | 90 nm |
| TDP unverified | 7 W |
| PCIe version unverified | 1.0 |
| Total PCIe lanes (chipset) unverified | 16 |
| DMI version unverified | 1.0 |
| Memory support unverified | DDR2 400/533/667 |
| Max memory unverified | 4 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports unverified | 4 |
| USB 2.0 ports unverified | 8 |
| Release date unverified | 2006-01 |
| Release year unverified | 2006 |
| Successor unverified | Intel 965PM |
| Predecessor unverified | Intel 915PM |
