Intel · 2015
Intel B150
The Intel B150 is a desktop chipset for LGA 1151 processors, released in 2015.
The Intel B150 is a desktop chipset released in 2015, part of the Sunrise Point family. It supports LGA 1151 sockets and is built on a 22 nm process with a TDP of 6 W. The chipset provides 8 PCIe 3.0 lanes, 6 SATA III ports, 6 USB 3.2 Gen 1 ports, and 12 USB 2.0 ports. It supports up to 64 GB of DDR3L or DDR4 memory across two channels, but does not support ECC memory. Integrated Ethernet is available via an integrated MAC. It includes Intel Rapid Storage Technology but does not support CPU or memory overclocking. The B150 is designed for use with Intel Skylake processors and was discontinued.
Specifications
| Socket unverified | LGA 1151 |
|---|---|
| Platform | Desktop |
| Process node | 22 nm |
| TDP | 6 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 8 |
| DMI version | 3.0 |
| Memory support unverified | DDR3L/DDR4 |
| Max memory unverified | 64 GB |
| Memory channels | 2 |
| ECC memory support | No |
| SATA III ports | 6 |
| USB 3.2 Gen 1 ports | 6 |
| USB 2.0 ports | 12 |
| Integrated Ethernet | Integrated MAC |
| Intel Rapid Storage Technology | Yes |
| CPU overclocking | No |
| Memory overclocking (XMP/EXPO) | No |
| Release date unverified | 2015-09-01 |
| Release year | 2015 |
| Discontinued | Discontinued |
| Notes unverified | CodeName: SunrisePoint |
