Intel BD82HM55
The Intel BD82HM55 is a mobile chipset released in 2010 for 1st generation Core i series processors.
The Intel BD82HM55 is a mobile chipset introduced in January 2010, designed for use with 1st generation Intel Core i series processors. It features a TDP of 3.5 W and supports DDR3 memory with a maximum capacity of 8 GB across two channels. The chipset provides 4 SATA III ports, 12 USB 2.0 ports, and 6 PCIe 2.0 lanes. It includes an integrated MAC for Ethernet but lacks Wi-Fi, Bluetooth, Thunderbolt, and USB 3.2 Gen 1 support. The BD82HM55 does not support ECC memory, Intel Rapid Storage Technology, vPro, CPU overclocking, or memory overclocking. It is available in a BGA form factor.
Specifications
| TDP unverified | 3.5 W |
|---|---|
| PCIe version unverified | 2.0 |
| Total PCIe lanes (chipset) unverified | 6 |
| DMI version unverified | 1.0 |
| Memory support unverified | DDR3 |
| Max memory unverified | 8 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports unverified | 4 |
| USB 3.2 Gen 1 ports unverified | 0 |
| USB 2.0 ports unverified | 12 |
| Thunderbolt support unverified | No |
| Integrated Ethernet unverified | Integrated MAC |
| Integrated Wi-Fi unverified | No |
| Integrated Bluetooth unverified | No |
| Intel Rapid Storage Technology unverified | No |
| vPro support unverified | No |
| CPU overclocking unverified | No |
| Memory overclocking (XMP/EXPO) unverified | No |
| Supported form factors unverified | BGA |
| Release date unverified | 2010-01 |
| Release year unverified | 2010 |
| Notes unverified | Mobile chipset for 1st gen Core i series |
