Intel · 2012
Intel BD82HM75
The Intel BD82HM75 is a mobile chipset released in 2012, featuring Intel Rapid Storage Technology and support for up to 6 SATA III ports.
The Intel BD82HM75 is a mobile chipset introduced on April 1, 2012, and is now discontinued. It has a thermal design power (TDP) of 4.1 W. The chipset provides 8 PCIe 2.0 lanes and supports up to 6 SATA III ports and 12 USB 2.0 ports. It includes Intel Rapid Storage Technology for enhanced storage performance and data protection. This chipset is designed for use with compatible mobile processors from the same era.
Specifications
| Platform | Mobile |
|---|---|
| TDP | 4.1 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 8 |
| SATA III ports | 6 |
| USB 2.0 ports | 12 |
| Intel Rapid Storage Technology | Yes |
| Release date | 2012-04-01 |
| Release year | 2012 |
| Discontinued | Discontinued |
