Intel BD82PM55
The Intel BD82PM55 is a mobile chipset for first-generation Core i processors, released in 2009.
The Intel BD82PM55 is a mobile chipset part of the Ibex Peak-M platform, designed for first-generation Intel Core i processors. It uses the LGA 1156 socket and is built on a 45 nm process with a TDP of 3.5 W. The chipset supports DDR3 memory with two channels and a maximum capacity of 16 GB, but does not support ECC memory. It provides 6 SATA III ports, 14 USB 2.0 ports, and an integrated MAC for Ethernet. The chipset has 8 PCIe 2.0 lanes and uses DMI 1.0 for connection to the CPU. It does not support Intel Rapid Storage Technology, vPro, CPU overclocking, or memory overclocking. The BD82PM55 was succeeded by the HM55 chipset.
Specifications
| Socket unverified | LGA 1156 |
|---|---|
| Platform unverified | Ibex Peak-M |
| Process node unverified | 45 nm |
| TDP unverified | 3.5 W |
| PCIe version unverified | 2.0 |
| Total PCIe lanes (chipset) unverified | 8 |
| DMI version unverified | 1.0 |
| Memory support unverified | DDR3 |
| Max memory unverified | 16 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports unverified | 6 |
| USB 3.2 Gen 1 ports unverified | 0 |
| USB 2.0 ports unverified | 14 |
| Thunderbolt support unverified | No |
| Integrated Ethernet unverified | Integrated MAC |
| Intel Rapid Storage Technology unverified | No |
| vPro support unverified | No |
| CPU overclocking unverified | No |
| Memory overclocking (XMP/EXPO) unverified | No |
| Supported form factors unverified | Mobile |
| Release date unverified | 2009-09 |
| Release year unverified | 2009 |
| Successor unverified | HM55 |
| Notes unverified | Dedicated mobile chipset for first-generation Core i processors. |
