Intel · 2009
Intel BD82QM57
The Intel BD82QM57 is a mobile chipset for LGA 1156 processors, released in 2009 as part of the Ibex Peak-M platform.
The Intel BD82QM57 is a mobile chipset released in September 2009, part of the Ibex Peak-M platform. It supports LGA 1156 sockets and is built on a 45 nm process with a TDP of 3.4 W. The chipset provides PCIe 2.0 with 8 lanes, DMI 1.0, and dual-channel DDR3 memory up to 8 GB without ECC support. It includes 6 SATA III ports and 14 USB 2.0 ports, and features Intel vPro technology. This chipset is designed for use with compatible LGA 1156 processors in mobile platforms.
Specifications
| Socket unverified | LGA 1156 |
|---|---|
| Platform unverified | Ibex Peak-M |
| Process node unverified | 45 nm |
| TDP unverified | 3.4 W |
| PCIe version unverified | 2.0 |
| Total PCIe lanes (chipset) unverified | 8 |
| DMI version unverified | 1.0 |
| Memory support unverified | DDR3 |
| Max memory unverified | 8 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports unverified | 6 |
| USB 2.0 ports unverified | 14 |
| vPro support unverified | Yes |
| Release date unverified | 2009-09 |
| Release year unverified | 2009 |
