Intel BD82QM67
The Intel BD82QM67 is a mobile chipset for Sandy Bridge processors, released in 2011 as part of the Cougar Point-M family.
The Intel BD82QM67 (QM67) is a mobile chipset introduced in 2011 for the Sandy Bridge generation of processors. It uses the LGA 1155 socket and is built on a 32 nm process with a TDP of 3.9 W. The chipset supports up to 16 GB of dual-channel DDR3 memory without ECC support. It provides 8 PCIe 2.0 lanes and features 2 SATA III ports and 14 USB 2.0 ports, but no USB 3.0. Integrated Gigabit Ethernet is included, but Wi-Fi and Bluetooth are not. The chipset supports vPro technology but not CPU or memory overclocking. It is designed for UCFF (4" x 4") form factors and was discontinued in 2013, succeeded by the QM77.
Specifications
| Socket unverified | LGA 1155 |
|---|---|
| Platform unverified | Cougar Point-M |
| Process node unverified | 32 nm |
| TDP unverified | 3.9 W |
| PCIe version unverified | 2.0 |
| Total PCIe lanes (chipset) unverified | 8 |
| DMI version unverified | 2.0 |
| Memory support | DDR3 |
| Max memory | 16 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports unverified | 2 |
| USB 3.2 Gen 2 ports unverified | 0 |
| USB 3.2 Gen 1 ports unverified | 0 |
| USB 2.0 ports unverified | 14 |
| Integrated Ethernet | 10/100/1000 |
| Integrated Wi-Fi | No |
| Integrated Bluetooth | No |
| Intel Rapid Storage Technology | No |
| vPro support unverified | Yes |
| CPU overclocking unverified | No |
| Memory overclocking (XMP/EXPO) unverified | No |
| Supported form factors | UCFF (4" x 4") |
| Release date unverified | 2011-02-20 |
| Release year unverified | 2011 |
| Discontinued | 2013 |
| Successor unverified | QM77 |
| Predecessor unverified | QM57 |
| Notes unverified | Part of Cougar Point-M chipset family for Sandy Bridge mobile processors. |
